End of Life Notice
* Effective Date: 2017/09/01
» High Definition AMD® R-series APU
» Four independent HDMI™ display video outputs
» Fanless design supporting 0ºC ~ 50ºC operating temperature
» SIM card support 3G/LTE wireless connection
» Support IPMI 2.0 via iRIS-2400 module
Hardware Spec.
| Color | |
|---|---|
| Color | Black |
| Dimensions | |
| Dimensions | 251 x 173.35 x 57 |
| Environment | |
| Humidity | 10% ~ 90%, non-condensing |
| Operating Temperature | 0°C ~ 50°C with air flow |
| Expansion Slots | |
| Expansion Slots | PCIe Mini:1 x Full size (supports mSATA), 1 x Half size |
| Form factor | |
| SBC Form Factor |
CPU:AMD® R-series R-260H 2.1 GHz Chipset:AMD® A70M System Memory: 2 x 204-pin DDR3 SO-DIMM (4GB pre-installed)(system max: 16GB) |
| I/O Interface | |
| I/O Ports |
2 x USB 3.0 2 x USB 2.0 Ethernet: 2 x RJ-45 1 x PCIe GbE by Intel® I210 1 x PCIe GbE by Intel® I211 RS-232:1 x RJ-45 Display:4 x HDMI™ Resolution:1920 x 1080@60Hz Audio:1 x Line-out, 1 x S/PDIF Other:1 x SIM standard card slot Wireless:802.1b/g/n 2T2R (optional) |
| System | |
| Cooling method / System Fan | Fanless |
| Drive Bays | 1 x 2.5' SATA 6Gb/s HDD/SSD drive bay |
| Weight | |
| Weight | 5.24 kg/6.5 kg |
Ordering Information
| IDS-200-A70Mi/4G-R10 | Fanless embedded system, AMD APU Dual Core R260H 2.1 GHz, TDP 17W, 4GB DDR3 SO-DIMM (2 x 2GB) pre-installed, 4 x HDMI™, iRIS-2400 optional, 10~30V DC input, R10, RoHS |
|---|
Package Contents
| Package Content |
|
|---|
