Industrial Applications on Embedded World 2020

Industrial Applications on Embedded World 2020

Industrial 4.0 is not just merely how to put your machines together, but how they can communicate smartly and maximize the efficiency and accuracy of your production line. IEI has provided a series of product lines which can cover across the factory, small box PCs for IoT gateways or displaying real time dashboards, high performance panel PCs serving as human machine interface, robust panel PCs for harsh environment, high-end systems for edge server and private network.

Industrial Applications product line

Edge servers plays a role to make the computational decisions ahead of time, sending only filtered data to the cloud, saving both time and money. Our TANK series, could work as a awesome edge server, high performance CPU platform, luxurious I/Os, and contain multiple expansion slots perfect to slot in add-on cards to run AI inference models, assisting your cloud to reduce work load and get data organized and filtered faster!

IDS-310-AL is a fanless ultra compact size box PC that contains multiple display output. In real time dashboard application, the dashboard contains visualizations that are automatically updated with the most current data available. These data visualizations offer a combination of historic data and real-time information that is useful for the production line to monitor efficiency. So processing these data is actually very time-sensitive, the solution needs to work fast and also able to aggregate and summarize real-time data, just like IEI’s IDS.

DRPC and ITG serves as great IoT gateways, enabling IoT communication, usually device-to-device communications or device-to-cloud communications. They house application software that performs essential tasks. At its most basic level, the gateway facilitates the connections between different data sources and destinations. In some cases, some sensors generates tens of thousands of data points per second. An IoT gateway provides a place to preprocess that data locally, minimizing the volume of data that needs to be forwarded on to the cloud or passed down to the edge server. This can also have a big impact on response time and network transmission costs.

LoRA Application

IEI DRPC serves as gateways, collecting data from various sensors set up across an area, the communication technology used between sensor devices and the gateway is LoRA. After preprocessing the data collected, DRPC than utilize other wireless communication which is faster, such as 4G or Wifi, to transport these summarized data to the could or backend server for further storage or analysis.

LORA-application

Product Highlights

PUZZLE-IN004 firewall appliance

PUZZLE-IN004 | X86-based Network Appliance New!

  • Intel® Xeon® D-2100 series processor (Skylake-D) with optional Intel QAT
  • Support eight GbE RJ-45 via IntelI211-AT, four 10 GbE SFP+ and IEI networking module
  • Support open source software, such as pfSense® and OPNsense®.
  • Support one PCIe x8 slot, one PulM module slot

Specifications - Product News


DRPC-130-AL Din-rail Embedded System

DRPC-130-AL | Fanless DIN-Rail Embedded System

  • Intel® Atom™ x5-E3930 1.3GHz (up to 1.8 GHz)
  • DDR3L 1.35V SO-DIMM supported
  • Serial, CAN bus and digital I/O interface

Specifications - Product News


IDS-310-AL | Fanless Ultra Compact Size Digital Signage System

IDS-310-AL | Fanless Ultra Compact Size Digital Signage System New!

  • Triple HDMI™ displays up to 4K resolution
  • Two GbE LAN ports
  • Full-size PCIe Mini slot and M.2 A-key slot for expansion

Specifications - Product News


AFL3-W07A-AL | IP65 Panel PC

AFL3-W07A-AL | IP65 Panel PC

  • W7” light industrial interactive panel PC
  • 12V DC input with lockable DC jack
  • Selectable AT/ATX power mode
  • On board IEEE802.3 at standard
  • Touch screen wth anti-UV / anti-glare coating

Specifications

New Products

PUZZLE-IN001A | x86-based Network Appliance

PUZZLE-IN001A | x86-based Network Appliance

  • Intel® Xeon® E, 8th & 9th Generation Intel® Core™/Pentium®/Celeron® processor
  • 8 x 5 GbE RJ-45 via AQC 111C
  • 4 x 288-pin DIMM, DDR4 2400MHz ECC & non ECC, up to 64 GB
  • 1 x RJ-45 Console, 2 x USB 3.2 Gen 1 (5Gb/s)
  • Support PCIe x4, PCIe x8 slot and two PulM module slots

Specifications - Prduct News


GRAND-C422-20D-H | AI Training System

GRAND-C422-20D-H | AI Training System

  • Intel® Xeon® W family processor supported
  • Up to 7 x PCIe Slot, up to 4 dual width GPU cards
  • Water cooling system on CPU
  • Support SAS SSD, 10GbE network, RAID controller card
  • Support one M.2 SSD M-key slot (NVMe PCIe 3.0 x4)

Specifications - Product News
