POCi-W22C-RPL
» Dual reading light
» Chemical etching AG coating
» Modular PCIe x4 expansion slot
» Aluminum front bezel (IP66) & PC/ABS rear cover
» FHD IPS panel with optional DICOM preset module
» 13th Generation Intel® Raptor Lake-P platform
» Built-in medical-grade power supply
Hardware Spec.
| Display | |
|---|---|
| LCD Size | 21.5” |
| LCD Resolution | 1920 x 1080 |
| LCD Brightness (cd/m²) | 350 |
| LCD Contrast Ratio | 1000:1 |
| LCD Color | 16.7M (RGB 8-bit) |
| LCD Pixel Pitch (mm) | 0.2745 (H) x 0.2745 (V) |
| LCD Viewing Angle (H-V) | 178°/178° |
| LCD Backlight MTBF | 50000 |
| Touch Screen | PCAP |
| Touch Controller | EETI |
| Touch Surface Hardness | 6H |
| Touchscreen Coating | Chemical etching AG |
| System | |
| Processor | 13th Gen Intel® Core™ i5-1340PE/ i7-1370PE (Raptor Lake-P) |
| Supported OS | Windows 11; Linux Ubuntu |
| Network | |
| Ethernet Controller | Intel® I226-V |
| Wi-Fi | IEEE 802.11 a/b/g/n/ac/ax, Intel® Wi-Fi 6E AX210 |
| Bluetooth | Bluetooth V5.2 |
| Storage | |
| Storage | 2 x M.2 2280 M key (PCIe/ SATA) with RAID |
| RAM | 2 x 262-pin 4800MT/s dual-channel DDR5 SO-DIMM slots (system max. 64GB) |
| Expansion Slots | |
| Expansion Slots |
1 x PCIe x2 1 x M.2 2230 A-E key (PCIe+USB) 2 x M.2 2260/80 B-M key (PCIe/ SATA) |
| Audio | |
| Speaker | 2 x 2W speaker |
| Microphone | 1 x Digital mic |
| I/O Interface | |
| Side I/O | 2 x USB 2.0 port |
| Rear I/O |
1 x AC jack 1 x HDMI output 1 x USB Type-C (DP + USB 5V/3A) 1 x Combo audio-out/mic-in 2 x RS-232 2 x 2.5GbE LAN port 4 x USB 3.2 Gen 2 (10Gb/s) port |
| Indicator&Buttons | |
| Buttons |
1 x Power on/off 1 x AT/ATX switch 1 x Reset button 1 x Clear CMOS Button |
| Indicators | 1 x Power indicator |
| Other Features | |
| OSD Function |
1 x Power on/off 1 x Reading light on/off 1 x Brightness up 1 x Brightness down 1 x LCD & touch lock on/off 1 x DICOM mode app on/off (optional) |
| Physical Characteristics | |
| Thermal | Fanless |
| Construction Material | ABS+PC plastic |
| Mounting | Wall, Stand and Arm; VESA 75/100 compliant |
| Weight (Net) (kg) | 6.9 kg |
| Dimensions (LxWxH) (mm) | 507.5 x 335.5 x 64.5 |
| Power | |
| Input | 85V – 264V AC input |
| Built-in Power Supply | 150W, 85V – 264V AC, medical power supply |
| Environment | |
| Operating Temperature | 0°C ~ 40°C |
| Storage Temperature | -20°C ~ 60°C |
| Humidity | 10% ~ 90% (non-condensing) |
| Vibration | 1G |
| Operating Shock | 5G peak acceleration (11ms duration) |
| Non-operating shock | 15G peak acceleration (11ms duration) |
| IP Level | Front: IP66 |
| Certifications | |
| Safety & EMC | CE, FCC Class B Part18, UL 60601-1, IEC/EN 60601-1, IEC/EN 60601-1-2 |
Ordering Information
| POCi-W22C-RPL-i7/PC-R10 | 21.5" 350cd/m² FHD medical panel PC with 13th generation 10nm Intel®Raptor Lake-P Core™ i7-1370PE 4.8GHz on-board processor,802.11a/b/g/n/ac/ax Wi-Fi 6E module,PCAP touchscreen w/ AG coating,R10 |
|---|---|
| POCi-W22C-RPL-i7/PC/DI-R10 | 21.5" 350cd/m² FHD medical panel PC with 13th generation 10nm Intel®Raptor Lake-P Core™ i7-1370PE 4.8GHz on-board processor,802.11a/b/g/n/ac/ax Wi-Fi 6E module,PCAP touchscreen w/ AG coating,DICOM,R10 |
| POCi-W22C-RPL-i5/PC-R10 | 21.5" 350cd/m² FHD medical panel PC with 13th generation 10nm Intel®Raptor Lake-P Core™ i5-1340PE 4.5GHz on-board processor,802.11a/b/g/n/ac/ax Wi-Fi 6E module,PCAP touchscreen w/ AG coating,R10 |
Package Contents
| Package Content |
|
|---|
