Embedded System

IEI, the leading embedded system provider, continues to extend the product footprint from component level to system integration service. Our strong knowledge of market and technology innovation offers reliability, flexibility and interoperability for all of our embedded products with choices of size, performance and features.
  • 製品一覧
    • >
  • 各種産業用 Box PC
    • >
比較狀態 :
已設定.要比較機種數 :
已設定.要比較機種 :
列表區塊.Now 位置狀態 :
列表區塊.單位區塊寬 :
列表區塊.Now X 位置 :
列表區塊.目標 X 位置 :
顯示框寬 :
列表寬 :
Din-rail Embedded System

DRPC Series

Fanless DIN Rail embedded system.
*User friendly installation design.
*OLED indicator function
*Fully integrated I/O
CPU
Expansion
DRPC-W-EHL1
icon-new

DRPC-W-EHL1

Fanless DIN-Rail Embedded System, Intel® Elkhart Lake Atom™x6000 Series Solution
● Supported CPU:
Onboard Intel® Atom™ x6000 series / Pentium® / Celeron® processor (Elkhart Lake platform)
Intel® Celeron® x6211E on-board SoC (up to 3.0 GHz, dual-core, 1.5M Cache, TDP=6W)
Intel® Celeron® x6413E on-board SoC (up to 3.0 GHz, quad-core, 1.5M Cache, TDP=9W)
Intel® Celeron® x6425E on-board SoC (up to 3.0 GHz, quad-core, 1.5M Cache, TDP=12W)
● Supported CPU:
Onboard Intel® Atom™ x6000 series / Pentium® / Celeron® processor (Elkhart Lake platform)
Intel® Celeron® x6211E on-board SoC (up to 3.0 GHz, dual-core, 1.5M Cache, TDP=6W)
Intel® Celeron® x6413E on-board SoC (up to 3.0 GHz, quad-core, 1.5M Cache, TDP=9W)
Intel® Celeron® x6425E on-board SoC (up to 3.0 GHz, quad-core, 1.5M Cache, TDP=12W)
● M.2:
1 x 2230 M.2 A Key (PCIe Gen3 x2 & USB 2.0)
1 x 3042 M.2 B Key (PCIe Gen3 x2 & USB 2.0)
● M.2:
1 x 2230 M.2 A Key (PCIe Gen3 x2 & USB 2.0)
1 x 3042 M.2 B Key (PCIe Gen3 x2 & USB 2.0)
View Products

DRPC-140 Right Side

DRPC-140-EHL

Fanless DIN-Rail Embedded System
● Supported CPU:
Intel® Celeron® J6412 2.0 GHz (up to 2.6 GHz, quad-core, TDP 10W)
● Supported CPU:
Intel® Celeron® J6412 2.0 GHz (up to 2.6 GHz, quad-core, TDP 10W)
● M.2:
1 x M.2 A Key 2230 (PCIe Gen3 x1/USB 2.0)
1 x M.2 M Key 2280 (PCIe Gen3 x2)
● M.2:
1 x M.2 A Key 2230 (PCIe Gen3 x1/USB 2.0)
1 x M.2 M Key 2280 (PCIe Gen3 x2)
View Products

DRPC-242-ADL-P Front

DRPC-242-ADL-P

Fanless DIN-Rail Embedded System
● Supported CPU:
Intel® Core™ i7-1370PE (up to 4.8GHz, 14-core, 28W TDP)
Intel® Core™ i7-1260P (up to 4.7GHz, 12-core, 28W TDP)
Intel® Core™ i5-1340PE (up to 4.5GHz, 12-core, 28W TDP)
Intel® Core™ i5-1240P (up to 4.4GHz, 12-core, 28W TDP)
Intel® Core™ i3-1320PE (up to 4.5GHz, 8-core, 28W TDP)
Intel® Core™ i3-1220P (up to 4.4GHz, 10-core, 28W TDP)
Intel® Celeron® 7305 (5-core, 15W TDP)
● Supported CPU:
Intel® Core™ i7-1370PE (up to 4.8GHz, 14-core, 28W TDP)
Intel® Core™ i7-1260P (up to 4.7GHz, 12-core, 28W TDP)
Intel® Core™ i5-1340PE (up to 4.5GHz, 12-core, 28W TDP)
Intel® Core™ i5-1240P (up to 4.4GHz, 12-core, 28W TDP)
Intel® Core™ i3-1320PE (up to 4.5GHz, 8-core, 28W TDP)
Intel® Core™ i3-1220P (up to 4.4GHz, 10-core, 28W TDP)
Intel® Celeron® 7305 (5-core, 15W TDP)
● M.2:
1 x 2230 A-key (PCIe Gen3 x1/USB 2.0) Support Vpro
1 x 3042/52 B-key (PCIe Gen3 x1/USB 3.2 Gen2/USB 2.0)
1 x On-board SIM card socket (hinge type) for M.2 B key
1 x 2280 M-key (PCIe Gen4 x4)
● Backplane:
1 x PCIe Gen3 x4 (optional)
● M.2:
1 x 2230 A-key (PCIe Gen3 x1/USB 2.0) Support Vpro
1 x 3042/52 B-key (PCIe Gen3 x1/USB 3.2 Gen2/USB 2.0)
1 x On-board SIM card socket (hinge type) for M.2 B key
1 x 2280 M-key (PCIe Gen4 x4)
● Backplane:
1 x PCIe Gen3 x4 (optional)
View Products

DRPC-124 Front right side

DRPC-124-EHL

Fanless DIN-Rail Embedded System
● Supported CPU:
Intel® Celeron® J6412 2.0 GHz (up to 2.6 GHz, quad-core, TDP 10W)
● Supported CPU:
Intel® Celeron® J6412 2.0 GHz (up to 2.6 GHz, quad-core, TDP 10W)
● M.2:
1 x 2242 B-key (PCIe Gen3 x2)
1 x 2242 B-key (SATA)
1 x 2280 M-key (PCIe Gen3 x2)
● M.2:
1 x 2242 B-key (PCIe Gen3 x2)
1 x 2242 B-key (SATA)
1 x 2280 M-key (PCIe Gen3 x2)
View Products

IEI DRPC-W-TGL DIN-Rail embedded system supports Tiger Lake 11 th Gen Intel® Celeron™ Solution

DRPC-W-TGL

Fanless DIN-Rail Embedded System Tiger Lake 11th Gen Intel® Celeron® Solution (up to 4 cores)
● Supported CPU:
Intel® Core™ i7-1185G7E 1.8 GHz (up to 4.4 GHz, quad-core, TDP 15W)
Intel® Core™ i5-1145G7E 1.5 GHz (up to 4.1 GHz, quad-core, TDP 15W)
Intel® Core™ i3-1115G4E 2.2 GHz (up to 3.9 GHz, dual-core, TDP 15W)
Intel® Celeron® 6305/6305E 1.8 GHz (dual-core, TDP 15W)
● Supported CPU:
Intel® Core™ i7-1185G7E 1.8 GHz (up to 4.4 GHz, quad-core, TDP 15W)
Intel® Core™ i5-1145G7E 1.5 GHz (up to 4.1 GHz, quad-core, TDP 15W)
Intel® Core™ i3-1115G4E 2.2 GHz (up to 3.9 GHz, dual-core, TDP 15W)
Intel® Celeron® 6305/6305E 1.8 GHz (dual-core, TDP 15W)
● M.2:
1 x M.2 A Key 2230 for WIFI & BT (optional)
1 x M.2 B Key (PCIe x2) 3042/3052 w/SIM slot for 5G (optional)
● M.2:
1 x M.2 A Key 2230 for WIFI & BT (optional)
1 x M.2 B Key (PCIe x2) 3042/3052 w/SIM slot for 5G (optional)
View Products

DRPC-W-JL Fanless DIN-Rail Embedded System Jasper Lake Intel® Celeron™ Solution

DRPC-W-JL

Fanless DIN-Rail Embedded System
Jasper Lake Intel® Celeron™ Solution (up to 4 cores)
Intel® Celeron® N5105 2.0 GHz (up to 2.9 GHz, quad-core, TDP 10W)
Intel® Celeron® N5105 2.0 GHz (up to 2.9 GHz, quad-core, TDP 10W)
● M.2:
1 x M.2 A Key 2230 for WIFI & BT (optional)
1 x M.2 B Key (PCIe x2) 2242/2280 w/SIM slot for 5G (optional)
● M.2:
1 x M.2 A Key 2230 for WIFI & BT (optional)
1 x M.2 B Key (PCIe x2) 2242/2280 w/SIM slot for 5G (optional)
View Products

DRPC-W-EHL Fanless DIN-Rail Embedded System with Elkhart Lake Intel® Celeron™ Solution

DRPC-W-EHL

Fanless DIN-Rail Embedded System
Elkhart Lake Intel® Celeron™ Solution (up to 4 cores)
● Supported CPU:
Intel® Celeron™ J6412 2.0 GHz (up to 2.6 GHz, quad-core, TDP 10W)
● Supported CPU:
Intel® Celeron™ J6412 2.0 GHz (up to 2.6 GHz, quad-core, TDP 10W)
● M.2:
1 x M.2 A Key 2230 for WIFI & BT (optional)
1 x M.2 B Key (PCIe x2) 3042 w/SIM slot for 5G (optional)
● M.2:
1 x M.2 A Key 2230 for WIFI & BT (optional)
1 x M.2 B Key (PCIe x2) 3042 w/SIM slot for 5G (optional)
View Products

DRPC-240-TGL-U Din-rail Embedded System

DRPC-240-TGL-U

Fanless DIN-Rail Embedded System with Tiger Lake 11 th Gen Intel® Core™ Solution (up to 4 cores)
Intel® Celeron® 6305E 1.8 GHz
Intel® Core™ i5-1145G7E 1.5 GHz
Intel® Core™ i7-1185G7E 1.8 GHz
Intel® Celeron® 6305E 1.8 GHz
Intel® Core™ i5-1145G7E 1.5 GHz
Intel® Core™ i7-1185G7E 1.8 GHz
●M.2:
1 x 2230 A-key
1 x 3042/52/80 B-key
1 x On-board SIM card socket (hinge type) for M.2 B key
●Backplane:
1 x PCIe x4
●M.2:
1 x 2230 A-key
1 x 3042/52/80 B-key
1 x On-board SIM card socket (hinge type) for M.2 B key
●Backplane:
1 x PCIe x4
View Products

DRPC-130-AL Din-rai Industrial Embedded System

DRPC-130-AL

Fanless DIN-Rail Embedded System
Intel® Atom™ x5-E3930 1.3GHz
Intel® Atom™ x5-E3930 1.3GHz
PCIe Mini:
1 x Half-size PCIe Mini slot
1 x Full-size PCIe Mini slot
PCIe Mini:
1 x Half-size PCIe Mini slot
1 x Full-size PCIe Mini slot
View Products
